DH-IPC-B1E29-A-IL 2MP ECO Smart Dual Light Fixed-focal Bullet Network Camera

Technical Specification
Camera
Image Sensor 1/2.8″ CMOS
Max. Resolution 1920 (H) × 1080 (V)
ROM 16 MB
RAM 64 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE);
0 lux (Illuminator on)
S/N Ratio ＞ 56 dB
Illumination Distance Up to 30 m (98.43 ft) (IR);
Up to 15 m (49.21 ft) (Warm light)
Illuminator On/Off Control Auto;Manual
Illuminator Number 2 (Multi-core (IR + warm) light)
Angle Adjustment
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Lens Mount M12
Focal Length 2.8 mm; 3.6 mm
Max. Aperture F1.6
Field of View 2.8 mm: H: 105°; V: 56°; D: 126°
3.6 mm: H: 87°; V: 44°; D: 105°
Iris Control Fixed
Close Focus Distance 2.8 mm: 0.7 m (2.30 ft)
3.6 mm: 1.3 m (4.27 ft)
DORI
Distance
Lens Detect Observe Recognize Identify
2.8 mm 43.9 m
( 144.03 ft)
17.5 m
( 57.41 ft)
8.8 m
( 28.87 ft)
4.4 m
( 14.44 ft)
3.6 mm 58.9 m
( 193.24 ft)
23.6 m
( 77.43 ft)
11.8 m
( 38.71 ft)
5.9 m
( 19.36 ft)
*DORI (Detect, Observe, Recognize, Identify) is a standard system
(EN-62676-4) for defining the ability of a person viewing the
video to distinguish persons or objects within a covered area.
The numbers in this table do not reflect intelligent function
distances. For intelligent function distances, refer to installation
and commissioning manual/project design tool.
Intelligence
Human Detection Support the classification and accurate detection of
human
Smart Search
Work together with Smart NVR to perform refine
intelligent search, event extraction and merging to
event videos
